Cisco 500 Series Administration Guide

Administration: Stack Management
Stack Ports
Cisco 500 Series Stackable Managed Switch Administration Guide 90
5
When you convert a device from one of the Stacking modes to Standalone mode,
the stack ports automatically become network ports.
Port Speeds
The speed of stack ports can be set manually or set to auto selection. The
following describes the available types of stack ports and their speeds on the
various types of devices:
Auto Selection of Port Speed
You can set the stacking cable type to be discovered automatically when the
cable is connected to the port (auto-discovery is the default setting). The system
automatically identifies the stack cable type and selects the highest speed
supported by the cable and the port.
A SYSLOG message (informational level) requesting that the user configures the
port speed manually is displayed when the cable type is not recognized.
Connecting Units
Two units can only be connected in a stack if the ports on both ends of the link are
of the same speed. This is done by configuring the stack ports speed to:
• Auto Speed mode
• Same speed on each side of the connection
Device Type Port Pair Possible Speeds in
Stack
Auto Speed
Selection
Available
Sx500 S1-S2 1G No
Sx500 S3-S4 5G/1G Yes
SG500X/
ESW2-550X
S1-S2-XG 10G/1G Yes
SG500X/
ESW2-550X
S1-S2-5G 5G/1G Yes
SG500XG Any pair of ports
from XG1 - XG16
1G or 10G Yes

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
