Cisco 500 Series Administration Guide

Cisco 500 Series Stackable Managed Switch Administration Guide 5
Contents
Chapter 13: Port Management: PoE 244
PoE on the Device 244
PoE Properties 247
PoE Settings 248
Chapter 14: VLAN Management 252
Overview 252
Regular VLANs 261
Private VLAN Settings 269
GVRP Settings 270
VLAN Groups 271
Voice VLAN 276
Access Port Multicast TV VLAN 289
Customer Port Multicast TV VLAN 292
Chapter 15: Spanning Tree 296
STP Flavors 296
STP Status and Global Settings 297
Spanning Tree Interface Settings 299
Rapid Spanning Tree Settings 301
Multiple Spanning Tree 304
MSTP Properties 304
VLANs to a MSTP Instance 305
MSTP Instance Settings 306
MSTP Interface Settings 307
Chapter 16: Managing MAC Address Tables 310
Static MAC Addresses 311
Dynamic MAC Addresses 312
Reserved MAC Addresses 313

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
