2-481
Catalyst 3550 Multilayer Switch Command Reference
OL-8566-01
Chapter 2 Catalyst 3550 Switch Cisco IOS Commands
show tcam
Command History
Usage Guidelines Expressions are case sensitive. For example, if you enter | exclude output, the lines that contain output
do not appear, but the lines that contain Output appear.
These displays provide information that might be useful for Cisco technical support representatives
troubleshooting the switch.
Examples This is an example of output from the show tcam inacl entries command for TCAM 1:
Switch> show tcam inacl 1 entries
Label Value: 8192(vlan label 0) Number of entries: 12
Ts - timestamp, Tb - TableId, L - L4OpSelect (IP) or lsapValid (MAC)
M - IP (1) or MAC (0), R - routerMacAddress
I - ipOption, S - lookupSize, Pl - Port Label, Vl - VLAN Label
F - fragmentInfo (IP) or IP header checksum error (MAC)
D - DSCP (IP) or IP header error (MAC)
T - tcpPacket (IP) or cos (MAC)
U - udpPacket (IP) or reserved bits (MAC)
MapR - l4MapResult (IP TCP/UDP) or l3 protocol type (MAC)
S-addr - source address, D-addr - destination address
S-pr - l4 source port (IP TCP/UDP) or IP protocol number
D-pr - l4 destination port or version and type (IP IGMP)
or type and code (IP ICMP)
Index Ts Tb L M R I S Pl Vl F D T U MapR S-addr S-pr D-addr D-pr As data
==============================================================================
4 msk F 0 1 0 0 1 00 FF 0 00 1 1 0000 00000000 00FF E0000000 0000
32 1 9 0 1 0 0 1 00 00 0 00 0 0 0000 00000000 0009 E0000000 0000 00260086
5 msk F 0 1 0 1 1 00 FF 2 00 1 1 0000 00000000 0000 E0000000 FFFF
33 4 9 0 1 0 0 1 00 00 0 00 0 1 0000 00000000 0000 E0000000 0208 00260086
6 msk F 0 1 1 0 1 00 FF 0 00 1 1 0000 00000000 00FE 00000000 0000
48 42 9 0 1 1 0 1 00 00 0 00 0 0 0000 00000000 0058 00000000 0000 00260086
7 msk F 0 1 1 0 1 00 FF 0 00 1 1 0000 00000000 00FF 00000000 0000
49 4 9 0 1 1 0 1 00 00 0 00 0 0 0000 00000000 0009 00000000 0000 00260086
7 msk F 0 1 1 0 1 00 FF 0 00 1 1 0000 00000000 00FF 00000000 0000
51 64 9 0 1 1 0 1 00 00 0 00 0 0 0000 00000000 0067 00000000 0000 00260086
8 msk F 0 1 1 1 1 00 FF 2 00 1 1 0000 00000000 FFFF 00000000 0000
64 1 9 0 1 1 0 1 00 00 0 00 1 0 0000 00000000 0001 00000000 0000 00260086
9 msk F 0 1 1 1 1 00 FF 2 00 1 1 0000 00000000 0000 00000000 FFFF
65 4 9 0 1 1 0 1 00 00 0 00 1 0 0000 00000000 0000 00000000 00B3 00260086
9 msk F 0 1 1 1 1 00 FF 2 00 1 1 0000 00000000 0000 00000000 FFFF
67 64 9 0 1 1 0 1 00 00 0 00 0 1 0000 00000000 0000 00000000 0208 00260086
10 msk F 1 1 0 0 1 00 FF 0 00 0 0 FFFF 000000000000 010000000000
80 44 9 0 0 0 0 1 00 00 0 00 0 0 0806 000000000000 010000000000 00260086
11 msk F 1 1 1 0 1 00 FF 0 00 0 0 FFFF 000000000000 000000000000
81 42 9 0 0 1 0 1 00 00 0 00 0 0 0806 000000000000 000000000000 00260086
IP default entry
204 msk F 0 1 0 0 1 00 FF 0 00 0 0 0000 00000000 0000 00000000 0000
1636 42 9 0 1 0 0 1 00 00 0 00 0 0 0000 00000000 0000 00000000 0000 00000082
non-IP default entry
205 msk F 0 1 0 0 1 00 FF 0 00 0 0 0000 000000000000 000000000000
1637 48 9 0 0 0 0 1 00 00 0 00 0 0 0000 000000000000 000000000000 00000082
Release Modification
12.1(4)EA1 This command was introduced.
12.1(9)EA1 The labels [label-id] keywords were replaced by port-labels [label-id] and
vlan-labels [label-id]
