2-132
Catalyst 3750 Switch Command Reference
OL-8552-07
Chapter 2 Catalyst 3750 Switch Cisco IOS Commands
dot1x auth-fail vlan
dot1x auth-fail vlan
Use the dot1x auth-fail vlan interface configuration command to enable the restricted VLAN on a port.
To return to the default setting, use the no form of this command.
dot1x auth-fail vlan vlan-id
no dot1x auth-fail vlan
Syntax Description
Defaults No restricted VLAN is configured.
Command Modes Interface configuration
Command History
Usage Guidelines You can configure a restricted VLAN on ports configured as follows:
• single-host (default) mode
• auto mode for authorization
You should enable re-authentication. The ports in restricted VLANs do not receive re-authentication
requests if it is disabled. To start the re-authentication process, the restricted VLAN must receive a
link-down event or an Extensible Authentication Protocol (EAP) logoff event from the port. If a host is
connected through a hub, the port might never receive a link-down event when that host is disconnected,
and, as a result, might not detect any new hosts until the next re-authentication attempt occurs.
If the supplicant fails authentication, the port is moved to a restricted VLAN, and an EAP success
message is sent to the supplicant. Because the supplicant is not notified of the actual authentication
failure, there might be confusion about this restricted network access. An EAP success message is sent
for these reasons:
• If the EAP success message is not sent, the supplicant tries to authenticate every 60 seconds (the
default) by sending an EAP-start message.
• Some hosts (for example, devices running Windows XP) cannot implement DHCP until they receive
an EAP success message.
A supplicant might cache an incorrect username and password combination after receiving an EAP
success message from the authenticator and re-use that information in every re-authentication. Until the
supplicant sends the correct username and password combination, the port remains in the restricted
VLAN.
Internal VLANs used for Layer 3 ports cannot be configured as restricted VLANs.
You cannot configure a VLAN to be both a restricted VLAN and a voice VLAN. If you do this, a syslog
message is generated.
vlan-id Specify a VLAN in the range of 1 to 4094.
Release Modification
12.2(25)SED This command was introduced.

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
