2-19
Catalyst 3750 Switch Command Reference
OL-8552-07
Chapter 2 Catalyst 3750 Switch Cisco IOS Commands
archive upload-sw
Usage Guidelines You must specify the /source-system-num option to use the /version option. Using these options
together uploads the specified image, not the running image, of a specific stack member.
Use the upload feature only if the HTML files associated with the embedded device manager have been
installed with the existing image.
The files are uploaded in this sequence: the Cisco IOS image, the HTML files, and info. After these files
are uploaded, the software creates the tar file.
Image names are case sensitive.
Examples This example shows how to upload the currently running image on stack member 6 to a TFTP server at
172.20.140.2:
Switch# archive upload-sw /source-system-num 6 tftp://172.20.140.2/test-image.tar
Related Commands Command Description
archive copy-sw Copies the running image from the flash memory on one stack member to the
flash memory on one or more other stack members.
archive download-sw Downloads a new image to the switch.
archive tar Creates a tar file, lists the files in a tar file, or extracts the files from a tar file.

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
