Cisco Catalyst 3750 User Manual

B-12
Catalyst 3750 Switch Command Reference
OL-8552-07
Appendix B Catalyst 3750 Switch Debug Commands
debug etherchannel
debug etherchannel
Use the debug etherchannel privileged EXEC command to enable debugging of the
EtherChannel/PAgP shim. This shim is the software module that is the interface between the Port
Aggregation Protocol (PAgP) software module and the port manager software module. Use the no form
of this command to disable debugging.
debug etherchannel [all | detail | error | event | idb]
no debug etherchannel [all | detail | error | event | idb]
Syntax Description
Note Though visible in the command-line help strings, the linecard keyword is not supported.
Defaults Debugging is disabled.
Command Modes Privileged EXEC
Command History
Usage Guidelines If you do not specify a keyword, all debug messages appear.
The undebug etherchannel command is the same as the no debug etherchannel command.
When you enable debugging, it is enabled only on the stack master. To enable debugging on a stack
member, you can start a session from the stack master by using the session switch-number privileged
EXEC command. Then enter the debug command at the command-line prompt of the stack member. You
also can use the remote command stack-member-number LINE privileged EXEC command on the stack
master switch to enable debugging on a member switch without first starting a session.
all (Optional) Display all EtherChannel debug messages.
detail (Optional) Display detailed EtherChannel debug messages.
error (Optional) Display EtherChannel error debug messages.
event (Optional) Debug major EtherChannel event messages.
idb (Optional) Display PAgP interface descriptor block debug messages.
Release Modification
12.1(11)AX This command was introduced.

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
