2-627
Catalyst 3750 Switch Command Reference
OL-8552-07
Chapter 2 Catalyst 3750 Switch Cisco IOS Commands
show lacp
show lacp
Use the show lacp user EXEC command to display Link Aggregation Control Protocol (LACP)
channel-group information.
show lacp [channel-group-number] {counters | internal | neighbor | sys-id} [ | {begin | exclude |
include} expression]
Syntax Description
Command Modes User EXEC
Command History
Usage Guidelines You can enter any show lacp command to display the active channel-group information. To display
specific channel information, enter the show lacp command with a channel-group number.
If you do not specify a channel group, information for all channel groups appears.
You can enter the channel-group-number option to specify a channel group for all keywords except
sys-id.
Expressions are case sensitive. For example, if you enter | exclude output, the lines that contain output
do not appear, but the lines that contain Output appear.
Examples This is an example of output from the show lacp counters user EXEC command. Table 2-32 describes
the fields in the display.
Switch> show lacp counters
LACPDUs Marker Marker Response LACPDUs
Port Sent Recv Sent Recv Sent Recv Pkts Err
---------------------------------------------------------------------
Channel group:1
channel-group-number (Optional) Number of the channel group. The range is 1 to 48.
counters Display traffic information.
internal Display internal information.
neighbor Display neighbor information.
sys-id Display the system identifier that is being used by LACP. The system
identifier is made up of the LACP system priority and the switch MAC
address.
| begin (Optional) Display begins with the line that matches the expression.
| exclude (Optional) Display excludes lines that match the expression.
| include (Optional) Display includes lines that match the specified expression.
expression Expression in the output to use as a reference point.
Release Modification
12.1(14)EA1 This command was introduced.
12.2(25)SE The channel-group-number range was changed from 1 to 12 to 1 to 48.

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
