2-523
Catalyst 3750 Switch Command Reference
OL-8552-07
Chapter 2 Catalyst 3750 Switch Cisco IOS Commands
show controllers power inline
Examples This is an example of output from the show controllers power inline command on a switch other than
a Catalyst
3750G-48PS or 3750G-24PS switch:
Switch> show controllers power inline
Module 1, Controller Instance 0, Address 0x40
Interrupt Reg 0x0 = 0x0
Intr Mask Reg 0x1 = 0xF6
Power Event Reg 0x2 = 0x0
Detect Event Reg 0x4 = 0x0
Fault Event Reg 0x6 = 0x0
T-Start Event Reg 0x8 = 0x0
Supply Event Reg 0xA = 0x0
Port 1 Status Reg 0xC = 0x24
Port 2 Status Reg 0xD = 0x24
Port 3 Status Reg 0xE = 0x3
Port 4 Status Reg 0xF = 0x3
Power Status Reg 0x10 = 0xFF
Pin Status Reg 0x11 = 0x0
Operating Mode Reg 0x12 = 0xAA
Disconnect Enable Reg 0x13 = 0xA0
Detect/Class Enable Reg 0x14 = 0xFF
Reserved Reg 0x15 = 0x0
Timing Config Reg 0x16 = 0x2
Misc Config Reg 0x17 = 0xA0
ID Revision Reg 0x1A = 0x64
Module 1, Controller Instance 1, Address 0x42
<output truncated>
This is an example of output from the show controllers power inline command on a
Catalyst
3750G-24PS switch:
Switch> show controllers power inline
Alchemy instance 0, address 0
Pending event flag :N N N N N N N N N N N N
Current State :00 05 10 51 61 11
Current Event :00 01 00 10 40 00
Timers :00 C5 57 03 12 20 04 B2 05 06 07 07
Error State :00 00 00 00 10 00
Error Code :00 00 00 00 00 00 00 00 00 00 00 00
Power Status :N Y N N Y N N N N N N N
Auto Config :N Y Y N Y Y Y Y Y Y Y Y
Disconnect :N N N N N N N N N N N N
Detection Status :00 00 00 30 00 00
Current Class :00 00 00 30 00 00
Tweetie debug :00 00 00 00
POE Commands pending at sub:
Command 0 on each port :00 00 00 00 00 00
Command 1 on each port :00 00 00 00 00 00
Command 2 on each port :00 00 00 00 00 00
Command 3 on each port :00 00 00 00 00 00
Related Commands Command Description
logging event
power-inline-status
Enables the logging of PoE events.
power inline Configures the power management mode for the specified PoE port or for all
PoE ports.
show power inline Displays the PoE status for the specified PoE port or for all PoE ports.

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
