Cisco CRS Configuration Guide

Related Topics
Configuring RSVP Packet Dropping, on page 127
Overview of RSVP for MPLS-TE and MPLS O-UNI , on page 112
Enable RSVP Traps: Example
The example enables the router to send all RSVP traps:
configure
snmp-server traps rsvp all
The example enables the router to send RSVP LostFlow traps:
configure
snmp-server traps rsvp lost-flow
The example enables the router to send RSVP RSVP NewFlow traps:
configure
snmp-server traps rsvp new-flow
Related Topics
Enabling RSVP Traps, on page 132
RSVP MIB, on page 117
Configuration Examples for RSVP Authentication
These configuration examples are used for RSVP authentication:
•
RSVP Authentication Global Configuration Mode: Example, on page 150
•
RSVP Authentication for an Interface: Example, on page 151
•
RSVP Neighbor Authentication: Example, on page 151
•
RSVP Authentication by Using All the Modes: Example, on page 152
RSVP Authentication Global Configuration Mode: Example
The configuration example enables authentication of all RSVP messages and increases the default lifetime of
the SAs.
rsvp
authentication
key-source key-chain default_keys
life-time 3600
!
!
The specified keychain (default_keys) must exist and contain valid keys, or signaling will fail.Note
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
150
Implementing RSVP for MPLS-TE and MPLS O-UNI
Enable RSVP Traps: Example

Cisco CRS Specifications

General

Operating System	Cisco IOS XR
Product Type	Core Router
Form Factor	Modular Chassis
Dimensions	Varies by chassis type
Weight	Varies by chassis type
Architecture	Distributed
Switch Fabric	Multi-stage
Interface Support	Ethernet, SONET/SDH, OTN
Interfaces/Ports	Varies by line card
Port Density	Varies by line card
Routing Protocol	BGP, IS-IS, OSPF, MPLS
Management	CLI, SNMP
Power Supply	Redundant, hot-swappable
Cooling	Redundant, Hot-swappable Fan Trays
Supported Protocols	IPv4, IPv6, MPLS
Management Interfaces	Ethernet, console
Security Features	ACLs
