PurposeCommand or Action
(Optional)
Checks for connectivity to a particular IP address (going through
MPLS LSP as shown in the show mpls forwarding
command).
ping ip-address
Example:
RP/0/RP0/CPU0:router# ping 192.168.2.55
Step 13
Related Topics
LDP Forwarding, on page 9
Configuring LDP Forwarding: Example, on page 81
Configuring Global Transport Address
Perform this task to configure global transport address for the IPv4 address family.
SUMMARY STEPS
1.
configure
2.
mpls ldp
3.
address-family ipv4
4.
discovery transport-address ip-address
5.
end or commit
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters MPLS LDP configuration mode.mpls ldp
Example:
RP/0/RP0/CPU0:router(config)# mpls ldp
Step 2
Enables LDP IPv4 address family.address-family ipv4
Example:
RP/0/RP0/CPU0:router(config-ldp)#
Step 3
address-family ipv4
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
42
Implementing MPLS Label Distribution Protocol
Configuring Global Transport Address
