PurposeCommand or Action
Enters the required MPLS-TE level or levels.
mpls traffic-eng level
Example:
RP/0/RP0/CPU0:router(config-isis-af)# mpls
Step 6
traffic-eng level-1-2
commit—Saves the configuration changes and remains within
the configuration session.
Use the commit or end command.
Step 7
end—Prompts user to take one of these actions:
• Yes— Saves configuration changes and exits the
configuration session.
• No—Exits the configuration session without committing
the configuration changes.
• Cancel—Remains in the configuration session, without
committing the configuration changes.
Configuring an OSPF Area of MPLS-TE
Perform this task to configure an OSPF area for MPLS-TE in both the OSPF backbone area 0 and area 1.
SUMMARY STEPS
1.
configure
2.
router ospf process-name
3.
mpls traffic-eng router-id ip-address
4.
area area-id
5.
interface type interface-path-id
6.
Use the commit or end command.
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
274
Implementing MPLS Traffic Engineering
Configuring an OSPF Area of MPLS-TE
