Cisco CRS Configuration Guide

Related Topics
Backup AutoTunnels, on page 168
Configure the MPLS-TE Auto-Tunnel Backup: Example, on page 356
Configuring a Prestandard DS-TE Tunnel
Perform this task to configure a Prestandard DS-TE tunnel.
Before You Begin
The following prerequisites are required to configure a Prestandard DS-TE tunnel:
•
You must have a router ID for the neighboring router.
•
Stable router ID is required at either end of the link to ensure that the link is successful. If you do not
assign a router ID to the routers, the system defaults to the global router ID. Default router IDs are subject
to change, which can result in an unstable link.
SUMMARY STEPS
1.
configure
2.
rsvp interface type interface-path-id
3.
bandwidth [total reservable bandwidth] [bc0 bandwidth] [global-pool bandwidth] [sub-pool
reservable-bw]
4.
exit
5.
exit
6.
interface tunnel-te tunnel-id
7.
signalled-bandwidth {bandwidth [class-type ct] | sub-pool bandwidth}
8.
Use the commit or end command.
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters RSVP configuration mode and selects an RSVP interface.
rsvp interface type interface-path-id
Example:
RP/0/RP0/CPU0:router(config)# rsvp interface
Step 2
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
231
Implementing MPLS Traffic Engineering
Configuring a Prestandard DS-TE Tunnel
