Cisco CRS Configuration Guide

PurposeCommand or Action
Example:
RP/0/RP0/CPU0:router(config-if)#
• Destination address is the remote node’s MPLS-TE router ID.
•
Destination address is the merge point between backup and
protected tunnels.
destination 192.168.92.125
Configures the dynamic path option and path ID.
path-option path-id dynamic
Example:
RP/0/RP0/CPU0:router(config-if)#
Step 8
path-option l dynamic
Configures a bidirectional optical tunnel for GMPLS.direction [bidirectional]
Example:
RP/0/RP0/CPU0:router(config-if)# direction
Step 9
bidirection
commit—Saves the configuration changes, and remains within the
configuration session.
Use the commit or end command.
Step 10
end—Prompts user to take one of these actions:
• Yes— Saves configuration changes and exits the configuration
session.
• No—Exits the configuration session without committing the
configuration changes.
• Cancel—Remains in the configuration mode, without
committing the configuration changes.
Configuring an Optical TE Tunnel Using Explicit Path Option
Perform this task to configure a numbered or unnumbered optical TE tunnel on a router. This task can be
applied to both the headend and tailend router.
You cannot configure dynamic tunnels on the tailend router.Note
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
261
Implementing MPLS Traffic Engineering
Configuring GMPLS
