Configure the Point-to-Multipoint Tunnel: Example, on page 363
Configure the Point-to-Multipoint Solution: Example, on page 364
Point-to-Multipoint Traffic-Engineering Overview, on page 193
Point-to-Multipoint RSVP-TE , on page 195
MPLS Traffic Engineering Shared Risk Link Groups
Shared Risk Link Groups (SRLG) in MPLS traffic engineering refer to situations in which links in a network
share a common fiber (or a common physical attribute). These links have a shared risk, and that is when one
link fails, other links in the group might fail too.
OSPF and Intermediate System-to-Intermediate System (IS-IS) flood the SRLG value information (including
other TE link attributes such as bandwidth availability and affinity) using a sub-type length value (sub-TLV),
so that all routers in the network have the SRLG information for each link.
To activate the SRLG feature, configure the SRLG value of each link that has a shared risk with another link.
A maximum of 30 SRLGs per interface is allowed. You can configure this feature on multiple interfaces
including the bundle interface.
Figure 17: Shared Risk Link Group illustrates the MPLS TE SRLG values configured on the bundle interface.
Figure 17: Shared Risk Link Group
Related Topics
Configuring the SRLG Values of Each Link that has a Shared Risk with Another Link, on page 294
Creating an Explicit Path With Exclude SRLG, on page 296
Using Explicit Path With Exclude SRLG, on page 298
Creating a Link Protection on Backup Tunnel with SRLG Constraint, on page 300
Creating a Node Protection on Backup Tunnel with SRLG Constraint, on page 303
Configure the MPLS-TE Shared Risk Link Groups: Example, on page 353
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
198
Implementing MPLS Traffic Engineering
MPLS Traffic Engineering Shared Risk Link Groups
