Cisco CRS Configuration Guide

SUMMARY STEPS
1.
configure
2.
mpls traffic-eng
3.
lmp neighbor name
4.
ipcc routed
5.
remote node-id node-id
6.
Use the commit or end command.
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Enters MPLS-TE configuration mode.mpls traffic-eng
Example:
RP/0/RP0/CPU0:router(config)# mpls traffic-eng
Step 2
Configures or updates a LMP neighbor and its associated
parameters.
lmp neighbor name
Example:
RP/0/RP0/CPU0:router(config-mpls-te)# lmp
Step 3
neighbor OXC1
Configures a routable Internet Protocol Control Channel
(IPCC).
ipcc routed
Example:
RP/0/RP0/CPU0:router(config-mpls-te-nbr-OXC1)#
Step 4
ipcc routed
Configures the remote node ID for an LMP neighbor. In
addition, the node-id value can be an IPv4 address.
remote node-id node-id
Example:
RP/0/RP0/CPU0:router(config-mpls-te-nbr-OXC1)#
Step 5
remote node-id 2.2.2.2
commit—Saves the configuration changes and remains within
the configuration session.
Use the commit or end command.
Step 6
end—Prompts user to take one of these actions:
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
252
Implementing MPLS Traffic Engineering
Configuring GMPLS
