Cisco CRS Configuration Guide

SUMMARY STEPS
1.
configure
2.
interface tunnel-mte tunnel-id
3.
ipv4 unnumbered type interface-path-id
4.
destination ip-address
5.
logging events lsp-status state
6.
logging events lsp-status reroute
7.
path-option preference-priority explicit name pathname
8.
exit
9.
fast-reroute
10.
Use the commit or end command.
11.
show mpls traffic-eng tunnels [p2mp]
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Configures an MPLS-TE P2MP tunnel interface.
interface tunnel-mte tunnel-id
Example:
RP/0/RP0/CPU0:router(config)# interface
Step 2
tunnel-mte 1000
RP/0/RP0/CPU0:router(config-if)#
Configures the MPLS-TE tunnel to use the IPv4 address on
loopback interface 0.
ipv4 unnumbered type interface-path-id
Example:
RP/0/RP0/CPU0:router(config-if)# ipv4 unnumbered
Step 3
loopback0
Sets the destination address for tunnel-mte from 1000 to
100.0.0.3.
destination ip-address
Example:
RP/0/RP0/CPU0:router(config-if)# destination
Step 4
100.0.0.3
RP/0/RP0/CPU0:router(config-if-p2mp-dest)#
Cisco IOS XR MPLS Configuration Guide for the Cisco CRS Router, Release 5.1.x
317
Implementing MPLS Traffic Engineering
Configuring Point-to-Multipoint TE
