Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
88
The IP menu has the following structure:
IP
Menu Item
Description
Parameters
Port ID
Select the Ethernet interface to
configure.
The D9854 has two interface ports.
Interface 1 is the control and
management interface and interface 2
is the data interface.
The D9854-I has three interface ports.
Interface 1 is the control and
management interface and interface 2
and interface 3 are data interfaces.
Description
Sets the description or name for the
Ethernet interface.
Up to 20 alphanumeric characters in
length.
V4/V6
Select the IP protocol.
Only IPv4 is currently supported.
IP Address
Sets the IPv4 IP address for the
interface.
12 digits in length (###.###.###.###)
Mask
Sets the number of CIDR (Classless
Inter-Domain Routing) bits in the
network mask.
8 to 30

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
