Cisco D9854 Installation And Configuration Guide

Setting up Audio and Video Information
209
Setting up Subtitles
1 From the user interface of the D9854/D9854-I, choose Audio & Video >
Subtitles. The Subtitles page is displayed.
2 From the Subtitle Control drop-down list, choose the subtitle control to use to
display the program subtitles. The following table describes each of the available
options:
Op Mode Selection
Description
Off
No subtitles are displayed.
On
Displays DVB or Imitext subtitles, if available.
DVB
Displays only DVB titles, if available. Otherwise, no subtitles are
displayed.
Imitext
Displays only Imitext subtitles, if available. Otherwise, no subtitles
are displayed.
3 From the Imitext Position drop-down list, choose position of the on-screen
subtitle text (Standard or Extended).
4 The Imitext Foreground Colour sets the color for Imitext subtitles. Auto displays
text in the color transmitted by the subtitling equipment. Yellow and White
overrides the color set by the uplink and display text in the selected color.
5 The Imitext Background Color sets the text background for Imitext subtitles. The
following table identifies the affect each setting has on the displayed subtitle text:
BackGnd Option
Description
Auto
Uses the uplink subtitling equipment setting.
