Cisco D9854 Installation And Configuration Guide

Setup Menu
87
Menu Item
Description
Parameters
Frequency Tuning
Indicates whether tuning is
using the NIT to tune to other
transports, or whether tuning is
forced to use the user selected
parameters.
NIT or User Cfg
Re-Acquire
Menu Item
Description
Parameters
Re-Acquire
Re-acquires the signal using the
tuning parameters from user
settings.
Abort or Continue. Select Abort to
cancel the operation or choose Continue
to complete the operation.
Setup Menu: IP
To view the IP menu from the Main menu, press the RIGHT arrow key once and the
then the SELECT key to reach the Setup menu. Then, press the RIGHT arrow key
twice and the SELECT key to view the IP menu.
The IP menu allows you to set the parameters for communicating with other
equipment via the Ethernet Data and Management ports for MPEGoIP and MPE
applications and upgrading application software.
For instructions on how to select and store settings, see About the Front Panel (on
page 44).

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
