Cisco D9854 Installation And Configuration Guide

13
Overview
This chapter provides a quick setup for your Cisco D9854/D9854-I
Advanced Program Receiver. If you are unsure about which receiver
settings to use, contact your local service provider for assistance.
2 Chapter 2
Quick Setup - Read Me First!
In This Chapter
 Connecting the Receiver to Other Equipment .................................14
 Setting up for Network Connection..................................................16
 Quick Setup Instructions for RF Acquisition ...................................17
 Assigning a Program Channel to a PE (Program Entry) .................19
 ASI Out................................................................................................20
 Setting up the HD-SDI Outputs (SDI Model, with SD/HD-SDI
and AES outputs) ...............................................................................21
 Setting up the MOIP Outputs............................................................22
 Setting the DPM Mode.......................................................................23

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
