Cisco D9854 Installation And Configuration Guide

Setup Menu
137
Setup Menu: CA
To view the CA menu from the Main menu, press the RIGHT arrow key once and
then the SELECT key to reach the Setup menu. Then press the RIGHT arrow key six
times and the SELECT key to view the CA menu.
The CA menu provides information about the ISE, the status of the ADP
transmission, and allows you to set the BISS mode and session words available from
your service provider. The CA menu has the following structure:
BISS-E ESW BISS-E IID
**************** **************
i
s
BISS Mode BISS-1 SW
Mode 1 ************
i
s
Id User Address ISE Version
1 123-456-7890-1 3.3(2)
i
CA
Id ADP Enc Pass ADP Enc Total
1 0 0
i
Id ADP Non-Enc Pass ADP Non-Enc Tot
1 0 0
i
Clear ADP Counts
Yes
i
s
Menu Item
Description
Parameters
Id
Select the ISE to configure.
1
User Address
Indicates the ISE User Address.
11 digit address in the following
format: ###-###-####-#
ISE Version
Indicates the ISE version number.
7 characters
ADP Enc Pass
Indicates the number of encrypted
Addressable Data Packets
successfully processed. Ideally, the
ADP Enc Pass and ADP Enc Total
numbers should be identical.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
