Setup Menu
139
Menu Item
Description
Parameters
BISS-E IID
If BISS Mode is Mode E, enter the
injected ID.
14-character password. Once
entered, it cannot be viewed and
it is only displayed as asterisks
(*).
Contact your program provider
for the session word.
Setup Menu: Alarm/Warning
To view the Alarm/Warning menu from the Main menu, press the RIGHT arrow
key once and then the SELECT key to reach the Setup menu. Then press the RIGHT
arrow key seven times and the SELECT key to view the Alarm/Warning menu.
The Alarm/Warning menu allows to you to browse the active alarms and warnings,
and set whether the output will be disabled in the event of an alarm. This menu has
the following structure:
FP Alarm Reminder Alarm Vid Cutoff
Disable Disable
i
s
Alarm/Warning
System Alarm Name Enb Rly Trp
Loss Of Signal Yes Yes Yes
i
s
System Warning Name Enb Rly Trp
PMT Timeout Yes Yes Yes
i
s
Menu Item
Description
Parameters
FP Alarm Reminder
Select whether to display
alarms and warnings on the
front panel. The alarm indicator
will intermittently flash in the
lower line, if enabled.
Enable or Disable
