Cisco D9854 - Contact Closure Interface

Control, Management and Data Interfaces
385
Item
Specification
Type of connector
15-pin sub-D female
Max. voltage
40 V peak
Max. current
0.5A
Contact Closure Interface
Item
Specification
Connector type
15-pin sub-D female
Minimum duration of event
guaranteed to be detected
250 ms, 1 frame period, e.g., for 1080i/25 Hz 40
ms for DPI applications
Max. on generator impedance
100 ohms
Min. off generator impedance
100 kilohms
