Cisco D9854 Installation And Configuration Guide

Setting up Input Information
187
Viewing the Disaster Recovery Status
From the user interface of the D9854/D9854-I, choose Input > Disaster Recovery
Status. The Disaster Recovery Status page is displayed.
The State field displays the current disaster recovery status. The table below lists the
statuses.
State
Description
No Disaster - D/R Ready
The unit is in a normal state and no disaster recovery is
in progress. It is set to use the local or uplink disaster
recovery settings (depending on the Configured By
field).

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
