Cisco D9854 Installation And Configuration Guide

Chapter 5 Web GUI Setup and Monitoring
188
State
Description
D/R in progress
The unit has detected a loss of input and if the
Configured By field displays User, it searches for a
backup transport using the configured search path. The
configured search path is displayed in the Backup
Transport area.
If the Configured By field displays Uplink, it searches
for a backup transport using the disaster recovery profile
from the PNC uplink.
D/R disabled - Maintenance
Mode
The disaster recovery feature is disabled. The unit is in
maintenance mode. To enable disaster recovery, see
Configuring the Disaster Recovery Settings (on page
183).
D/R disabled
The disaster recovery feature is disabled by the PNC
uplink. Contact your PNC uplink administrator.
No Disaster - D/R Ready
(Transport Only)
The unit is in a normal state and no disaster recovery is
in progress. It is set to use the uplink disaster recovery
settings. The unit receives a search path with backup
transports only. However, the amount of data for the
backup plan service in the Disaster Recovery Table (DRT)
exceeds the allowable limit from the current unit. Contact
your PNC uplink administrator to reduce the amount of
backup plan IDs in the Uplink Configuration.
No Disaster - D/R Not Ready
(No Search Path)
The unit is in a normal state, but the unit is not ready for
disaster recovery due to a missing search path from the
PNC uplink. The following lists possible reasons:

Tuning descriptors in the DRT is empty. As a result,
no match has been found for the origin.

Tuning descriptors in the DRT consists of only one
tuning parameter, which matches the origin. As
other tuning descriptors are empty, there are no
transports for the search path.
Contact your PNC uplink administrator.
No Disaster - D/R Not
Ready (Malformed DRT)
The unit is in a normal state, but the unit is not ready for
disaster recovery due to the DRT received from the
uplink is malformed. The following is a list of the
possible reasons:

DRT Valid flag in the DRT is set to FALSE.

Customer code in the ADP does not match the
customer code in the DRT header.

Disaster ID in the ADP does not match the ID in the
DRT header.
Contact your PNC uplink administrator.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
