Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
154
EMC
PID of the channel's Entitlement Control Message stream. It is displayed as ----
if unavailable or not scrambled.
Program Name
Name of the channel.
PSI - Tables
This is the Tables received sub-menu. You cannot make any changes here, but you
can view the PSI tables received and their settings. Press the UP and DOWN arrow
keys to scroll through the list of tables.
Menu Item
Description
Parameters
Type
The MPEG table acronym.
PAT, CAT, PMT, TSDT, NIT, NIT
Other, SDT, SDT Other, BAT,
AEIT P/F, OEIT P/F, TDT, RST,
ST, TOT, DIT, SIT, ECM Odd,
ECM Even, EMM, MPE, DPI,
DRT, CDT, MCT, MIT, MAT,
ECT, or Invalid Table ID
Tbl-ID
Unique Table ID.
ID
MPEG/DVB Table ID.
Ver
Table Version number.
PID
Value of the PID on which the table is
present.
Status
Reception status of the table.
None, Partial, Full, Update,
Timeout, or Lost
Sections
Number of sections in the table.
Power On
Menu Item
Description
Creation Date and
Time
Displays the date and time the current unit was manufactured.
Power On Date and
Time
Displays the date and time the current unit was last powered up, in relation to
the current local time.
Total Hrs
Displays the total number of hours the current unit has been running since
being manufactured.
Hrs Since Last
Pwroff
Displays the number of hours the current unit has been running since the last
power on.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
