Cisco D9854 Installation And Configuration Guide

Status Menu
59
Menu Item
Description
Parameters
Act
Displays whether the selected service
is inserted.
Yes - The selected service is
inserted.
No - The selected service is not
enabled by the user or not present.
Adj
Displays the line number where
the selected service is expected to
be inserted by the hardware (for
the top field if it is an interlaced
video, or for the frame if it is a
progressive video). If Multiline is
not supported, the Adj value is set
to Switch line + 2. For more
information, see SDI - Global (on
page 57).
–
L-F1/L-F2
Displays which line on Field 1 and
Field 2 the selected service is present.
If the service is not inserted, 0 is
displayed.
–
Lines
Displays the number of video lines
used to send data for the selected
service.
–
Avg Data
Displays the number of words per
frame the selected service occupies.
–
Pkt OK
Displays the number of transmitted
data packets, per frame, for the
selected service.
–
Pkt Drop
Displays the number of dropped data
packets for the selected service.
–
Status Menu: TS Input
Input
Menu Item
Description
Parameters
Input
Indicates the active input port receiving
the signal.
RF1, RF2, RF3, RF4, ASI, or IP
