Status Menu
57
Menu Item
Description
Parameters
FPS
Indicates the frame rate of the input
video stream.
Typically 25.0, 29.97, 30.0, 50.0,
59.94, 60.0, unknown or
unsupported
Stream AR
Indicates the aspect ratio of the
incoming video stream.
4:3, 14:9 or 16:9
Act Conv
Displays the actual applied aspect
ratio conversion.
None, 4:3 L/B, 4:3 P/B, 14:9, 14:9,
4:3 F/H or 16:9 F/W
Audio
Menu Item
Description
Parameters
AUD
Indicates the current audio decoder
status.
AUD1 for audio channel Aud1.
AUD2 for audio channel Aud2.
AUD1 to AUD4 for two stereo
audio channels.
Format
Indicates the format of the audio
input stream.
None, Sine, Pink, Beep, MPEG1L1,
MPEG1L2, MPEG2L1, MPEG2L2,
AC3, LOAS AAC, ADTS AAC,
LOAS HEAAC, ADTS HEAAC, or
DDP
BR (Kbps)
Indicates the bit rate of the audio
input stream, in kbps.
Buffer
Indicates the buffer level of the input
audio stream, in bytes.
SFR (Kkz)
Indicates the sample rate of the input
audio stream, in kHz.
32.0, 44.1, or 48.0 kHz
DDP IND
Indicates the presence of Dolby
Digital Plus frames within a Dolby
Digital Plus audio stream.
OFF or ON
DUAL-MONO IND
Indicates the presence of dual mono
audio outputs in the audio stream. If
the dual mono indicator is set to ON,
the left and right outputs will
correspond to mono channel 1 and
mono channel 2 respectively.
OFF or ON
