Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
152
Diagnostics Menu
To view the Diagnostics menus from the Main menu, press the RIGHT arrow key
four times and then the SELECT key.
For instructions on how to select and store settings, see About the Front Panel (on
page 44).
The Diagnostics menu has the following structure:
Alarms/Warnings
Menu Item
Description
View History
Select to view the system event messages. Press the UP and DOWN arrow
keys to scroll through the list of alarms and warnings. Press the LEFT and
RIGHT arrow keys to view the set and reset times. Press the INFO key to
view the detailed message.
Clear History
Select to clear any existing history information.
Logs
Menu Item
Description
View Logs
Select to view the system log messages. Press the UP and DOWN arrow keys
to scroll through the list of log messages. Press the INFO key and then UP and
DOWN arrow keys to view the complete message text.
Clear Logs
Select to clear any existing log history information.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
