Cisco D9854 Installation And Configuration Guide

Appendix B
Default Settings and Lock Levels
390
Factory Default Settings and Lock Levels
The D9854/D9854-I Advanced Program Receiver is factory configured with default
settings unless you have requested a custom factory configuration.
The following table lists the lock levels available for protecting your receiver and its
settings against unauthorized use or modification:
Level
Description
0
All settings are unlocked (receiver lockout disabled)
1
All settings are unlocked except Factory Reset,
Password options and receiver parameters.
2
All settings are unlocked except RF and ASI Input
Tuning parameters.
3
All settings locked (access via password only), except IP
address and RF power.
4
All settings locked (can be changed via PNC uplink
signal only)
If a change made to the current Lock Level setting is not saved, the previously saved setting
is restored.
Administration
Parameter
Default Setting
Default Lock Level
Lock Level
0
3
Password
1234
3
Old Pwd, New Pwd, Confirm
Pwd
N/A
0
Factory Reset
N/A
0
Clear FWD Tables
N/A
0
KB Lock
Disable
2
KB Lock Timeout
60
2
LCD Contrast
30
2
DL Mode
Always
2
Type
None
N/A
Bank
App 5514
N/A

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
