Transport Stream Inputs/Outputs
381
Transport Stream Inputs/Outputs
ASI Output
Item
Specification
Number of outputs
1
Type of connector
75 ohms BNC
Output impedance
75 ohms according to EN 50083-9
Data amplitude
800 mV peak-peak ± 10% according to EN 50083-
9
Return loss
>17 dB, 27 to 270 MHz
Transport stream data rate
1 to 80 Mbps descrambling/decoding (for D9854)
1 to 180 Mbps descrambling, 1 to 80 Mbps
decoding (for D9854-I)
ASI Transmission Rate
270 MBaud ± 100 ppm
Transport stream formats
According to EN 50083-9
188 bytes structure
Burst or packet format
MPEGoIP Output
Item
Specification
Number of outputs
2
Type of connector
RJ-45, 100/1000BASE-T
Output modes
UDP, RTP
Redundancy Mode (D9854-I
only)
Manual, Auto, or Mirroring
IP Addressing
Multicast or Unicast
TS Streaming
1 MPTS
up to 32 SPTS (D9854-I only)
TS Bit Rate
1 to 80 Mbps descrambling/decoding (for D9854)
1 to 180 Mbps descrambling, 1 to 80 Mbps
decoding (for D9854-I)
MPEGoIP bit rate
Up to 206 Mbps

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
