Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
86
Menu Item
Description
Parameters
NIT
If using custom tune mode,
select whether to use the
Network Information Table
(NIT) when creating the service
list.
Yes or No
SDT
If using custom tune mode,
select whether to use the Service
Description Table (SDT) when
creating the service list.
Yes or No
PAT
If using custom tune mode,
select whether to use the
Program Association Table
when creating the service list.
Yes or No
Frequency Tuning
If using custom tune mode,
select whether to use the NIT to
tune to other transports, or to
force the tuning to user
configuration settings.
NIT or User Cfg.
NIT - The receiver can change tuning
parameters to use all transports available
in the NIT.
User Cfg - The receiver is forced to use
the user selected tuning parameters.
Status
Menu Item
Description
Parameters
Service List Mode
Indicates if all the expected
service list tables are present
(Rigorous) or only some of the
service list tables are present
(Degraded)
Degraded or Rigorous
BAT
This is not supported in the
current release.
No
NIT
Indicates whether the Network
Information Table (NIT) is being
used to create the service list.
Yes or No
SDT
Indicates whether the Service
Description Table (SDT) is being
used to create the service list.
Yes or No
PAT
Indicates whether the Program
Association Table (PAT) is being
used to create the service list.
Yes or No

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
