Cisco D9854 Installation And Configuration Guide

Setup Menu
85
Menu Item
Description
Parameters
Revertive Delay
Time to wait before reverting back to the
primary port once the primary port is active
again.
Note: If Non-Revertive is set as the Type, this
field does not apply.
0 to 30 seconds
A/V Trigger
If set to Yes, it will trigger the MPEG over IP
input redundancy failover if audio/video loss
is detected.
Yes or No
PCR Trigger
If set to Yes, it will trigger the MPEG over IP
input redundancy failover if program PCR loss
is detected.
Yes or No
Prog Trigger
If set to Yes, it will trigger the MPEG over IP
input redundancy failover if program PMT
loss is detected.
Yes or No
Idx
The IP address entry number (index) for the
Source Filter list.
IP Address
If White List is selected as the Src Filter, the
unit will only receive streams from the trusted
IP addresses listed.
If Black List is selected as the Src Filter,
the unit will receive all streams except
from the IP addresses of hosts listed.
Press ADV to enter an address.
Valid host IP address
Tune Mode
Custom
This menu is where you set up your custom properties. Select the channel to set up
and then edit it.
Menu Item
Description
Parameters
Services List Mode
If using custom tune mode,
select which tables are required
for tuning.
Degraded or Rigorous.
Rigorous - Requires all service list tables
to be present to acquire the signal.
Degraded - Requires any service list
table to be present to acquire the signal.
BAT
This is not supported in the
current release.
No
