Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
84
Menu Item
Description
Parameters
FEC2 UDP
If FEC is set to 2D, in addition to entering the
port number of the column FEC stream, enter
the FEC destination UDP port number of the
row FEC stream.
2 to 65534
Source IP Select
Displays the detected host.
Valid host IP address or
0.0.0.0 if none is found.
DATA1/DATA2
Displays whether the detected host (Source IP
Select) is available on DATA1 and/or DATA2
ports.
Yes or No
Algorithm
The de-jitter algorithm.
VBR, CBR
Latency (ms)
Buffer latency (delay), in milliseconds.
110 to 150 if VBR is
selected as the Algorithm.
40 to 150 if CBR is selected
as the Algorithm.
Redundancy Mode
Select the type of redundancy for the MOIP
input data.
Manual Data1/Data2 -
Only use Data1 (port 1) or
Data2 (port 2) for input
data. The remaining
redundancy controls
below are not applicable.
Backup: Primary
Data1/Data2 - Use port 1
or port 2 as the primary
data port. If an issue
occurs, it will failover to
port 2 or port 1 (the
backup port).
Type
If Backup: Primary Data1/Data2 is set as the
Redundancy mode, select the redundancy
direction.
Revertive - Attempt to
revert back to the primary
port when using the
backup port and the
primary port is active
again.
Non-revertive - Use the
backup port (if active)
when the primary port
fails, without reverting
back to the primary port,
under any condition.
Direct Delay
Time to wait before switching from the
primary data port to the backup data port after
the system detects a failure on the primary
port.
0 to 1000 milliseconds

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
