Chapter 4 Front Panel Operation
Sets the three digit tone
sequence.
Sets the tone sequence mode.
* - Start tone only
# - End tone only
*/# - Start and end tones. The end
tone is signaled after waiting the time
specified in Delay(sec).
If the Mode was set to */#
(Start/Stop), set the delay, in
seconds, between the start and
stop sequences.
1 to 255. The default is 30.
The relay can be programmed
to respond to an alarm or
warning state, or the state of
one of the eight cue trigger
pins. The response is generated
at the Cue Tone/Relay output
on the rear panel of the
receiver.
Alarm or Trigger
The following table displays the
possible field settings and their
relationship to the receiver output:
If the Relay Mode was set to
Trigger, select the cue trigger
bit/pin that will activate the
relay.
Sets the three digit cueing tone
test sequence.
Sets the test sequence mode.
* - Start tone
# - End tone
Select and press continue to run
the cue tone test according to
the Cue Tone Test and Mode.
