Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
118
Menu Item
Description
Parameters
Config Type
Indicates the current DPM
configuration change by a user
after changing the Output
Mode.
Edited by User - DPM changes were made.
Unmodified - No changes were made after
setting a new Output Mode.
Auto Re-Mapped - Output map changed
automatically to fix the output channel or
PID conflicts at the time of setup.
Changed by Uplink - DPM output changes
were initiated by an encoder.
Descramble Mode
Select whether the output will
be descrambled if the input is
scrambled.
Scrambled - The output channel will remain
scrambled even if the PE is authorized and
can descramble the channel.
Descrambled - Descrambles the output
channel, and passes in-the-clear channels.
The default is Descrambled.
Insert Null Packet
Select whether to insert null
packets into the output to
maintain output at a constant
bit rate.
Yes or No
Auto Map
Sets whether the DPM resolves
the channel and PID collisions
automatically on the transport
outputs. New values are
assigned to the parameters that
caused the conflict. The new
assigned values are not used by
any incoming transport or other
PE outputs. If a collision is
detected, you can review the
new changes before applying
the new changes.
Yes or No
MOIP
Menu Item
Description
Parameters
Name
This is the name assigned to the
transport output for ease of
reference.
20-character string

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
