Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
124
Menu Item
Description
Parameters
FEC1 UDP
Enter the destination UDP port
number of the columns FEC
stream.
2 to 65534, even number only
FEC2 UDP
Enter the destination UDP port
number of the rows FEC
stream.
2 to 65534, even number only
FEC Columns (L)
Set the spacing between non-
consecutive packets used to
calculate the FEC packet.
1 to 20
FEC Rows (D)
Set the depth of the FEC matrix.
4 to 20
TS Out - DPM
To view the DPM menu from the TS Out menu, press the RIGHT arrow key. The
DPM menu provides access to functionality associated with Global, ASI, and MOIP
outputs.
The DPM menu allows you to groom functionality on a program basis where
individual service PID modifications are provided on a limited scale.
Use the digital program mapping features to:
 configure the transport output bit rate
 configure the output mode for a program entry
 configure the service and PID output settings in a program entry
Note: Any changes made to the ASI/MOIP DPM values will automatically change
the Config Type to Edited by User.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
