Cisco D9854 Installation And Configuration Guide

Chapter 5 Web GUI Setup and Monitoring
218
7 From the Relay Mode drop-down list, choose the relay mode that can be
programmed to respond to an Alarm state, Warning statue, or the state of one of
the eight cue trigger pins. The response is generated at the Cue Tone/Relay
output on the rear panel of the receiver. The following table shows what the
possible field settings are and their relationship to the receiver output:
Relay Mode
Condition
Relay Contact
NC - C
C-NO
Alarm
Unit Power Off
Open
Close
Alarm State
Open
Close
No Alarm
Close
Open
Trigger
Active (selected in PNC)
Close
Open
Inactive
Open
Close
8 If the Relay Mode is set to Trigger, choose the cue trigger bit/pin that will
activate the relay from the Relay Trigger Bit drop-down list (1 to 8).
9 Click Apply.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
