Chapter 5 Web GUI Setup and Monitoring
f The Avg Data column displays the number of words per frame the service
occupies.
g The Pkt OK column displays the number of transmitted data packets per
frame for the service.
h The Pkt Drop column displays the number of dropped data packets for the
service.
4 In the SDI Audio Group Setup area, you can choose the audio channel group
and audio channels from the available audio group. The following describes the
parameters:
Displays the channel group (1 to 4).
Displays the HANC position (1 to 4).
Choose the audio source (1 or 2).
Choose the source audio channel (Left or Right).
5 The status table displays the current SDI information. The following describes
the parameters:
Displays whether the video is interlaced.
Displays the video resolution (number of lines per
frame).
Displays the range of inactive video lines (First to Last)
for the current video format. The VANC data is inserted
in the video line(s), following the Switch line. The
numbers are for the top field if it is an interlaced video,
or for the frame if it is a progressive video.
Note: The SMPTE standard recommends using lines
starting from Switch line + 2.
Displays the number of frames per second.
Displays the number of VANC words per line.
Displays whether Multiline VANC insertion is
supported. For D9854 with SDI units, this is only
supported in the current FPGA implementation
(R00.00.05). If a previous FPGA version is installed,
Multiline is not supported until you upgrade the FPGA.
6 Click Apply.
