Configuring Transport Stream Information
The output map changed automatically to fix the output channel
or PID conflicts at the time of setup.
DPM output changes were initiated by an encoder.
6 From the Descrambled drop-down list, choose whether the output will be
descrambled if the input is scrambled. The following table describes the available
options:
The output channel will remain scrambled even if the PE is
authorized and can descramble the channel.
Descrambles the output channel, and passes in-the-clear channels.
7 From the Null Packet Insertion drop-down list, choose Yes to insert null packets
into the output to maintain output at a constant bit rate. Otherwise, choose No.
Note: We recommend that you set the Null Packet Insertion ito Yes, especially if
the Output Mode is set to Transcoding.
Click Apply.
Setting Up the ASI Auto Synchronization Options
The ASI Auto Sync area allows you to configure the DPM without editing each
output channel and PID separately.
1 In the ASI Outputs page (Transport Stream > ASI Output), refer to the ASI
Auto Sync area.
2 From the Enable Auto Fix for Collision drop-down list, choose Yes for the DPM
to resolve channel and PID collisions automatically on the transport outputs.
New values are assigned to the parameters that caused the conflict. The new
assigned values are not used by any incoming transport or other PE outputs. If a
collision is detected, you can review the new changes and click Apply to accept
the new changes.
Choose No and a detailed list of all the conflicts is displayed in the Output
Channel and PID Conflicts table (click View Conflicts) when a conflict occurs.
You can then resolve the conflicts manually.
