Configuring Transport Stream Information
4 If necessary, from the Descrambled drop-down list, choose whether the program
is to be scrambled or descrambled for downstream viewing or monitoring.
5 Click Apply.
6 Click Transport Stream > Digital Program Mapping for ASI Output or MPEG
over IP Output. The ASI or MPEGoIP Digital Program Mapping page is
displayed.
7 Click Resynchronize All. This copies the input services PIDs to the remapped
output service PIDs.
8 Click the radio button of the PE containing the channel you want to configure
and click Edit. The DPM PE PID MAP dialog box is displayed.
9 Click Add Row.
10 From the Action drop-down list, choose Drop or Map.
11 Choose the input to output channel mapping from the Category drop-down list.
Video and PCR can be output on the same PID or different PIDs. If output on the
same PID, they will appear identical to the input.
12 Click Save.
13 Click OK.
14 In the DPM General Setting area, set the following parameters:
15 Click Table Options. The DPM Table Options (ASI) dialog box is displayed.
16 Set the following parameters:
