Cisco D9854 Installation And Configuration Guide

DPM Default Settings for Different Output Modes
405
Output Mode
No Output
Passthrough
Service
Chans Only
MAP
Passthrough
MAP Svc
Chans Only
Full DPM
Control
TDT
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
RST
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
TOT
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
DIT
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
SIT
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
ECM
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
EMM
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
DRT
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
CDT
Not
Displayed
Pass
Pass
Pass
Pass
Actual
Value
PE Action (all
PEs)
Drop
Pass
Pass
Map
Map
Actual
Value
The following table contains values passed to the DPM for the D9854 with MOIP and D9854-I
only:
Output Mode
SPTS Service Chans
Only
SPTS MAP Svc
Chans Only
SPTS Full DPM
Control
Map Mode
Svc ID & PID
Svc ID & PID
Actual Value
Duplic Mode
Pkt Copy
Pkt Copy
Pkt Copy
Unref
Drop
Drop
Drop
PSI Options
Ctl By Table
Ctl By Table
Actual Value
PSI Rate
SA Std
SA Std
Actual Value
Svc ID
Valid Ch
Valid Ch
Actual Value
PAT
Regen
Regen
Actual Value
CAT
Regen
Regen
Actual Value
PMT
Regen
Regen
Actual Value
TSDT
Drop
Drop
Actual Value

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
