D9854/D9854-I Receiver Rear Connector Panel
Asynchronous Serial Interface Input.
One Asynchronous Serial Interface Output.
TS Outputs
TS Inputs/Outputs
(D9854-I only)
This is for the MPEGoIP and MPE outputs.
The MPEGoIP output transmits the
decrypted transport stream encapsulated in
IP packets to a groomer for distribution. The
MPE output receives and outputs the IP
data packets from the incoming transport
stream.
The MPEGoIP input (D9854-I only) allows
the decoder to receive its streams from the
terrestrial IP network.
Supports the following network protocols:
Telnet, SSHv2, HTTP, HTTPS, SNMPv2,
Syslog/DTX, SNTP, FTP (client side), TFTP,
and MPEGoIP output (D9854 only).
M1 and M2 provide HD serial digital video
with embedded audio output for HD
applications according to SMPTE-292M.
RS-232 data output: 7 bits, even parity, 1
stop bit, up to 38.4 kb/s. These outputs are
user-configurable via the Setup menu on
the front panel.
Cue Tone/Cue Trigger
Relay Outputs
Program relay provides programmed
responses for alarms, cue trigger states for
ad-insertion equipment, or a cue tone
output for connection to ad-insertion
equipment.
CVBS 1 and CVBS 2 provide two identical
SD composite video outputs for monitoring
applications.
SD to HD upconverted component video
output for HD monitoring applications.
AES-3id outputs. One output for each stereo
channel.
Audio 1 and Audio 2 provide two stereo
pairs or four mono channels.
Grounding point for
the receiver
