Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
62
Menu Item
Description
Parameters
Polar
Indicates the polarity of the LNB Power
supply.
Off, 13V, or 18V
LO Select
Indicates whether a 22 kHz tone is
available on input port RF1. This is
applicable for dual-band applications.
On or Off
Program PIDs
Menu Item
Description
Parameters
PE
Select the Program Entry to view.
PE1 to PE16
Stream
Indicates the name assigned to the
Program Entry.
Up to 4 alphanumeric
characters
Detail
Indicates any detail associated with
the program PID (e.g., MPG2 PID).
MPG1 VID, MPG2 VID, 422
VID, H264 VID, HD VID, MPG4
VID, MPG AUD, MPG2 AUD,
DVB AC3, DVB DDP, AAC
AUD, HEAAC, AUD, MPG4
AUD, DBE AUD, DTS AUD,
DVB TXT, DVB VBI, DVB
SUBT, DVB ASYN, DVB SYNS,
DVB SYND, DVB MPE, DVB
DCAR, DVB OCAR, SA VBI,
ATSC AC3, ATSC DDP, SA
UTLD, SCTE DPI, SA HSD, SA
CDDL, SA WBD, SA SUBT,
ECM, EMM, PCR, or
UNKNOWN
PID
Indicates the program PID number.
1 to 8191
Present
Indicates whether the PID is present
in the incoming stream.
Yes or No
Program Status
Menu Item
Description
Parameters
PE
Select the Program Entry number to
view.
PE1 to PE16
