Cisco D9854 Installation And Configuration Guide

Status Menu
65
Redundancy Status
Note: This feature is for D9854-I only.
Menu Item
Description
Parameters
Ports in Use
The current output port in use.
None, Data1, Data2, or
Both
Change Reasons
Description of the reason for the last redundancy
status change.
Link, Setup, or
Setup+Link
Change Date &
Time
Displays the last date and time the redundancy
status changed.
YYYY/MM/DD
HH:MM:SS
MOIP Out Global Status
Menu Item
Description
Parameters
Engine Error
Indicates a critical hardware error that may require
a unit reboot.
Yes or No
Stream Overflow
Indicates the MPEG over IP transport stream(s)
overflow status.
Yes or No
Combined User
Rate
Displays the combined output bit rate for all the
configured streams (including FEC).
Actual Rate Port
1/2
Displays the current output bit rates for Data1 and
Data2 ports (including FEC).
0 to 206 Mbps
MOIP Out Stream Status
Menu Item
Description
Parameters
PE ID
Displays the program entry channel.
1 to 16
Stream Port1/Port2
Indicates the stream status of the Management and
Data ports (D9854), or Data1 and Data2 ports
(D9854-I).
Stopped, Suspended,
Active, or Muted
Content Overflow
Indicates if the rate of the transport stream(s) to be
encapsulated (including FEC) is higher than the
configured output bit rate.
Yes or No
Link Overflow
Indicates if the configured output bit rate
(including FEC) is close or higher than the current
Ethernet link speed for the Ethernet port used for
MPEGoIP output.
Yes or No

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
