[opcode]
Specify “any” to apply ACL rule to both
reply and request frames; “reply” to
denote reply frames; “request” to
denote request frames.
[source_ip]
This is sender IP filtering function.
Specify “any” to filter frames from any
sender IP addresses. Or, specify either
a host IP address (x.x.x.x).
[ip_mask]
Define source IP mask.
“any”: Specify “any” to mean any IP
mask.
“255.255.0.0”: Specify a specific IP
mask.
[dest_ip]
This is destination IP filtering function.
“any”: Specify “any” to filter frames to
any destination IP addresses.
“x.x.x.x”: Specify either a host IP
address or a network address.
[ip_mask]
Define destination IP mask.
“any”: Specify “any” to mean any IP
mask.
“255.255.0.0”: Specify a specific IP
mask.
[arp_smac_match]
This is to configure whether ARP
source MAC sent and received are
matched or not.
“any”: Specify “any” to denote both a
match and not a match.
“0”: Denote not a match.
“1”: Denote a match.
[rarp_dmac_match]
This is to configure whether RARP
destination MAC sent and received are
matched or not.
“any”: Specify “any” to denote both a
match and not a match.
“0”: Denote not a match.
“1”: Denote a match.
