Data Format
Product Reference Guide 235
Label ID: Set Individually Per Symbology — continued
Table 17
STEP ACTION EXAMPLES
1.
Scan the ENTER/EXIT bar
code
(Scanner enters Programming Mode)
2.
Determine placement of the
Label ID characters BEFORE
or AFTER w
ith regard to
scanned data using
"Label ID
Control" on page 49
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting
the symbology type you
wish to designate label ID
characters for using
Label ID
Symbology Selection, starting on
page 50
.
GS1 DataBar
Omnidirectional
Code 39 Interleaved 2 of 5 Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from
the ASCII table (inside
back
cover), then scan in these
digits/characters using the
bar codes in the section:
Keypad, starting on page 267 . f
you make a mistake before
the last character, scan the
CANCEL bar code to abort
and not save the entry
string. You can then start
again at the beginning.
44 42 2A 3D 43 33 2B 50 48
6.
Scan the ENTER/EXIT bar
code
(Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT bar
code once again
(Scanner exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code
data]
[bar code data]PH
. Label ID Examples
