Product Reference Guide
243
Appendix A
Technical Specifications
The table below contains Physical and Performance Characteristics, User Environment and
Regulatory information.
Table 23 provides Standard Cable Pinouts.
Table 22. Technical Specifications
Item Description
Electrical Features
Power Supply
RS-232 interface 5 Vdc
5%
Consumption:
Max operating current @ 5V: <500 mA
Typical operating (changing colors) current @ 5V < 430 mA
Standby mode/USB suspend < 2,5 mA
Max. Scan Rate 1500 lines/sec.
Reading Indicators
Ring of light and top indicator Illumination,
Beep or jingle
Optical and Read Performance
Ambient Light Immunity
Fluorescent, incandescent, mercury vapor and sodium vapor: 450 ft-candles
(4,844 lux)
Sunlight: 8,000 ft-candles (86,111 lux)
Motion Tolerance On 100% EAN13 @ 10cm from nose: > 4 m/sec.
Scan Technology Laser
Wavelength 650 nm
Laser Safety Class Class 1 IEC 60825-1:2007
Reading Field
5 mils: 5 - 55 mm
100% EAN13: 0 to 275 mm
Max. Resolution 5 mils
PCS (Datalogic Test Chart) 35%
Environmental Features
Working Temperature 0
C to + 40
C (+32° to +104°F)
Storage Temperature -40
C to +70
C (-40° to +158°F)
Humidity 90% non-condensing
Drop Resistance 1.2 m
