Reading Parameters
Product Reference Guide 237
Reading Parameters
Label Gone Timeout
This feature sets the time after the last label segment is seen before the scanner prepares for
a new label. The timeout can be set within a range of 10 milliseconds to 2,550 milliseconds
(2.55 seconds) in 10ms increments. Label Gone Timeout does not apply to scan modes that
require a trigger pull for each label that is read
Follow these instructions to set this feature:
1. Determine the desired setting in milliseconds.
2. Divide the desired setting by 10 (setting is in 10ms increments). Pad the result with
le
ading zeroes to yield three digits. For example: 0 = 000, 5 = 005, 20 = 020, etc.
3. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming Mode.
4. Scan the bar code: SELECT LABEL GONE TIMEOUT SETTING.
5. Scan the appropriate three alpha-numeric characters
from the keypad in Appendix D, Key-
pad
representing the duration which was determined in the steps above. You will hear a
two-beep indication after the last character.
NOTE
If you make a mistake before the last character, scan the CANCEL bar code to
abort and not save the entry string. You can then start again at the begin-
ning.
6. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit Programming Mode.
This completes the procedure. See the table below
for examples of how to set this feature.
Table 18. Timeout Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
50ms 150ms
1800ms (1.8
se
c.)
2550ms (2.55 sec.)
2
Divide by 10 (and pad with
leading zeroes)
005 015 180 255
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT LABEL GONE TIMEOUT SETTING
5
Scan Three Characters From
Appendix D, Keypad
‘0’, ‘0’ and ‘5’ ‘0’, ‘1’ and ‘5’ ‘1’, ‘8’ and ‘0’ ‘‘2’, ‘5’ and ‘5’
6 Scan ENTER/EXIT PROGRAMMING MODE
