Error Codes
Upon startup, if the scanner sounds a long tone, this means the scanner has not passed its
automatic Selftest and has entered FRU (Field Replaceable Unit) isolation mode. If the scanner
is reset, the sequence will be repeated. The following table describes the LED flashes/beep
codes associated with an error found.
1 Configuration
Contact Helpdesk for assis-
tance
2 Interface PCB
5 [Reserved]
6 Digital PCB
Label Program-
ming Mode
Acceptance of
Partial Label
In cases where multiple labels
mu
st be scanned to program
one feature, this indication
acknowledges each portion as
it is successfully scanned.
N/A
Scanner sounds one short
be
ep at highest frequency &
current volume.
Label Program-
ming Mode
Acceptance of
Programming
Configuration option(s) have
be
en successfully pro-
grammed via labels and the
scann
er has exited Program-
ming Mode.
N/A
Scanner sounds one high fre-
quency beep and 4 low fre-
quency beeps followed by
re
set beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been
scann
ed.
N/A
Scanner sounds two times at
l
ow frequency and current
volume.
Programming Mode - The
following indications ONLY occur when the scanner is in Programming Mode.
INDICATION DESCRIPTION LED SPEAKER
NUMBER OF
LED
FLASHES/
BEEPS
ERROR CORRECTIVE ACTION
